API

曲线优美, 操作简单, 让您尽享诊断愉悦.


Automatic Remote Control Analysis

Still Image Capture

Android / iOS / Windows

StilEasy to Gripl Image Capture





API 100

水份 / 油份 / 毛孔
色斑 / 暗疮 / 皱纹
敏感度

API 202

脱发状态 / 头皮状态
头发密度 / 头发角质
头皮血管 / 头发厚度
头发毛孔状态

API 203

脱发状态 / 头发厚度
头发毛孔状态 / 毛鳞片状态


API 100
皮肤诊断




水份 / 油份 / 毛孔 / 色斑 / 暗疮 / 皱纹 / 敏感度


API 202
毛发诊断




脱发状态 / 头皮状态 / 头发密度 / 头发角质 / 头皮血管 / 头发厚度 / 头发毛孔状态


API 203
毛发诊断




脱发状态 / 头发厚度 / 头发毛孔状态 / 毛鳞片状态


Wi-Fi视频流解决方案


VGA (640×480) | 30 FPS Max, 2M (1600×1200) | 15 FPS Max


VGA视频图形阵列 / 2M静态图像捕捉


开始 | 模式转换 | 截图 | 诊断 | 结果


多系统支持


安卓 | iOS | Windows


SMARTPHONE

Android Smartphone, iPhone

DESKTOP

Windows PC

TABLET

Android Tablet, iPad, Windows Tablet

SPECIFICATION


ITEMAPI-100API-202API-203
Wi-Fi TypeWireless LAN IEEE 802.11 b/g/n
OS SupportAndroid, iOS, Windows
Image Sensor1/4 inch Color CMOS UXGA (2 Mega Pixel)
Sensor PixelEffective pixel : 1,624 X 1,212 Pixel
Image Capture SizeWi-Fi Video Streaming
VGA (640 X 480) | 2 M (1,600 X1,200)
Image Frame RateVGA (640X480) - 30Frame Max
2M (1,600 X1,200) - 15Frame Max
LEDDip LED X8 & UV-Chip LED X8
(NICHIA / Japan)
Dip LED X8
(NICHIA / Japan)
Dip LED X8
(NICHIA / Japan)
Camera Button FunctionStart, Mode Change, Image Capture, Analysis, Result
High Magnification Lens1. X30-NL
2. X30-PL
3. X30-UV
4. Moisture Sensor
1. X60-NL
2. X60-PL
3.X200-NL(Crop)
4.X200-PL(Crop)
1. X200-NL
2. X600-NL (Crop)
Measurement Mode 1. Moisture
2. Sebum (U/T Zone)
3. Pore
4. Melanin
5. Clearness of Pore (UV)
6. Wrinkle
7. Sensitivity
1.Hair Loss Status
2. Scalp Status
3. Hair Density
4. Keratin of Scalp
5. Sensitivity
6. Hair Thickness
7. Hair Pore Status
1. Hair Loss Status
2. Hair Thickness
3. Hair Pore Status
4. Cuticle Status
FocusingFixed Type
BatteryType: Li-ION / Typical Capacity: 1,150mAh
Normal Voltage: 3.7V
DC IN Adaptor5V DC / 2A
Out Dimension50(W)X162(H)X60(D)mm (API-100 / Camera Only )
WeightAbout 120g (API-100 / Camera Only / with Battery)
CradleStand
Operating Temperature-10 ~ 50°C
Storage Temperature-30 ~ 50°C
Operating Humidity5 ~ 85%
